Lathe
Highly Rigid Large CNC Lathe
TG-SeriesHighly Rigid Large CNC Lathe
TG-Series Highly Rigid Large CNC Lathe
1matches (1 - 1)
|
Lathe Large CNC Lathe TG-6000 Chuck Size 15～28in, Max.Turning Dia. 760mm, Max. Turning Length 1031, 2031, 3031, 4031mm
|
The TG-6000 series is a large lathe having incomparably high cutting capability.
It can correspond to machining of large parts for construction machine/shipbuilding, both-end thread cutting of large-diameter/long-pipe materials for oil industry, and the needs of wind power generation field.。
Big bore specification for both-end machining of large-diameter pipe
Spindle through-hole diameters up to 375 mm are available.
Applicable To Large Diameter And Long Workpieces
Large CNC lathe capable of Turning up to 4031 mm in maximum length and 760 mm in maximum turning diameter.
Tough turret, tailstock, bed and saddle construction presents powerful and stable cutting.
Highly Reliable rectangular Slideways Are Used In All Axes
Optimum wide slideway provides powerful and stable heavy-duty cutting performance and high durability.
